4-Axis Wet Glass Ceramic Milling Machine DN-W4Z for Dental Clinics and Milling Centers
Key Advantages
● Smart 1-to-10 Clustering
Allows a single PC to wirelessly manage up to 10 DN devices simultaneously for scalable, high-efficiency production.
● 0.01 mm High Precision
Features an advanced closed-loop drive system and 0.01 mm relocation accuracy for flawless marginal fit.
● Ultra-Fast Wet Milling
Delivers standard restorations (inlays, veneers, crowns) in 15–30 minutes, drastically boosting clinic turnover.
● Fully Open Architecture
Seamlessly accepts STL data from any intraoral scanner and integrates with professional WORKNC DENTAL CAM software.
● Industrial-Grade Stability
Built with an aviation-grade all-aluminum frame (370×466×370 mm, ~40 kg) that resists deformation and dust for a long lifespan.
● One-Touch Smart Operation
Features an intuitive touch interface, one-key clamping, and automatic tool changing for effortless, error-free workflows.
Applications
Parameters
|
Type of equipment |
Desktop |
|
Applicable materials |
Rectangular glass-ceramics；Li-based ceramics；Mixed materials；PMMA |
|
Type of processing |
Inlay and onlay; Veneer; Crown；Implant crown |
|
Working temperature |
20~40℃ |
|
Noise level |
~70dB（when working） |
|
X*Y*Z Stroke (in/mm) |
5 0×5 0×4 5 |
|
X.Y.Z.A semi-driven system |
Micro-step closed loop motors+ Preloaded ball screw |
|
Repeat positioning accuracy |
0.02mm |
|
Wattage |
Whole machine ≤ 1.0 KW |
|
Power of spindle |
350W |
|
Speed of spindle |
10000~60000r/min |
|
Way of tool changing |
Pneumatic automatic tool changer |
|
Way of material changing |
Pneumatic push-button，no tools required |
|
Magazine capacity |
Three |
|
Tool |
Shank diameter ¢4.0mm |
|
Pressure requirements of the air source for tool and material change |
Drying 4.5 to 8.5 kg/cm² |
|
Diameter of ball head |
0.5+1.0+2.0mm |
|
Supply voltage |
220V 50/60Hz |
|
Weight |
~40kg |
|
Size(mm) |
370×466×370 |
Pneumatic ATC (Air-Driven): Highly recommended for Milling Centers & Labs. It relies on an external air compressor, offering robust durability and low maintenance costs for continuous, high-volume production.
Electric ATC (Motor-Driven): Highly recommended for Dental Clinics (Chairside). It uses an internal micro-motor to change tools mechanically. With no heavy air compressor noise or extra piping needed, it ensures a much quieter and cleaner clinic environment.
